From Neuron to Calculation

The nervous system is a net of neurons each having a soma and an axon

From Neuron to Calculation

Their adjunctions, or synapses, are always between the axon of one neuron and the soma of another

From Neuron to Calculation

At any instant a neuron has some threshold, which excitation must exceed to initiate an impulse

From Neuron to Calculation

$y_k = \phi ( \displaystyle \sum_{j=1}^m w_{kj} x_j + x_0)$

From Neuron to Computation

$x_1 \textbf{ AND } x_2$

From Neuron to Computation

$x_1 \textbf{ OR } x_2$

From Neuron to Computation

$\textbf{NOT } x_1$

From Neuron to Computation

From Neuron to Computation

$x_1 \textbf{ XOR } x_2$

From Growth to Learning

How do we set the weights?

From Growth to Learning

The assumption, in brief, is that a growth process accompanying synaptic activity makes the synapse more readily traversed.

From Growth to Learning

When an axon in cell A is near enough to excite cell B and repeatedly and persistently takes part in firing it, some growth process or metabolic change takes place in one or both cells such that A’s efficiency in firing B is increased.

From Growth to Learning

Hebb's learning rule: fire together, wire together

Hebbian Learning

$\Delta w_{kj} = \eta x_j y_k$

change weight $i$ proportinally to the product of the input and the output

Hebbian Learning

$\Delta w_{kj} = \eta x_j y_k$

Problems?

Supervised Method

How do we find weights that can produce a particular output?

Hinton's Fish and Chips

• Diet of multiple portions of fish, chips, and ketchup
• Cashier only gives total price of meal

Hinton's Fish and Chips

• Start with random guesses for the price of each portion
• After multiple days, should be able to know prices of individual portions

Delta-rule

$\Delta w_{kj} = \eta ( t_k - o_k ) i_k$
